🔥 2,000 Watts. Mini Footprint. 1 Ohm Stable.

The DC Audio PS-2000x1 is a full-bridge compact monoblock amplifier capable of delivering a serious 2,000 watts RMS at 1 ohm — all in an ultra-compact chassis.

Designed to make more power in less space, this amp is ideal for:

• Subwoofer builds

• Full range stunt wall systems

• High-output door builds

• Pro audio mids & highs

With onboard clip lights, built-in cooling fan, and included wired bass knob, the PS-2000x1 gives you serious control and output in a small, efficient package.

💪 RMS Power Ratings (14.4V)

• 500W x 1 @ 4 Ohms

• 1,000W x 1 @ 2 Ohms

• 2,000W x 1 @ 1 Ohm

✔ 1 Ohm Stable
✔ Full Bridge Design
✔ High Power Mono Block

🎛 Built for Subwoofers OR Full Range

The built-in Full Range Switch allows this amp to power:

• Subwoofers

• Midbass drivers

• Pro Audio door builds

• Stunt walls

• Full range speaker systems

This flexibility makes it far more than just a sub amp.

⚙️ Key Features

• 1 Ohm Stable

• 9–16.5V Operating Voltage

• Variable Low Pass Filter (50Hz – 15kHz)

• Variable Subsonic Filter

• Bass Boost

• Wired Bass Knob Included

• Onboard Power / Protect / Clip Indicators

• Tiffany Style RCA Inputs

• 4 AWG Power & Ground Inputs

• Built-In Cooling Fan

• Super Compact Design

• Stackable in Amp Rack Systems

📊 Technical Specifications

Model: PS-2000.1
Input Sensitivity: 4V – 0.4V
Frequency Response: 10Hz – 20kHz
Crossover Slope: 12dB / Octave
Low Pass Filter: 50Hz – 15kHz
Subsonic Filter: Yes
Bass Boost: Yes
Full Range Switch: Yes
Phase Shift: No
Remote Level Control: Yes (Included)
Clip Indicator: Yes
Signal to Noise Ratio: 90dB
THD @ 4 Ohms: <0.1%
Fuse Rating: External 200A
LED Status Lights: Power / Protect / Clip
Master/Slave: No

📐 Dimensions

• Length: 6.82” (173mm)

• Width: 5.23” (133mm)

• Height: 2.3” (60mm)

Compact enough for tight installs, powerful enough for serious builds.

🔧 Ideal For

• 1–2 High Output Subwoofers @ 1 Ohm

• Compact 2K Daily Builds

• Pro Audio Door Systems

• Stunt Wall Systems

• Under-seat or hidden installs

• High output mids & highs setups

📦 What’s Included

• DC Audio PS-2000x1 Amplifier

• Wired Bass Knob Remote

• Mounting Hardware

• Owner Documentation

⚡ Installation & Electrical Notes

Professional installation recommended.
Use 4 AWG minimum wiring (upgrade recommended for high current systems).
Install proper fuse protection within 18” of battery.
Ensure adequate vehicle electrical support for 2,000W systems.
